V7E-L06G-R4030-Q2U, 400W Veichi servo motor, 1.27Nm, 3000rpm, Tamagawa 17Bit Single turn magnetic encoder, with brake, flange option:
CHF 287.74 excl.
Pilot=50mm, bolt circle=70mm, shaft=14mm. Veichi V7E Permanent magnet synchronous servomotor with 1.27Nm rated torque and maximum 4000rpm, Tamagawa 17Bit Single turn magnetic encoder Feedback and with brake
Available: Delivery time approx. 7 weeks
Veichi V7E Brushless PM servo motors:
The brushless V7 synchronous servomotors from Veichi offer high power density and reliability, low cogging torque. The slim connector guide allows the installation space to be optimally utilized.
- with brake
- Tamagawa 17Bit Single turn magnetic encoder encoder
- Veichi power and feedback connector, flange size 40mm
- Veichi encoder 7-pole, straight, screwed
- IP67
- Inertia 0.36kgcm²
Performance data
| Stall | |
| 1.27Nm | |
| 10.6A | Peak |
| 3.81Nm | |
| 31.8A | |
| 4000rpm | |
| 200V | |
| 48Vdc | |
| 1.27Nm | |
| 3000rpm |
Certifications: CE
Motor is part of a system with the corresponding SD100 servo controller
| Item no. | 9001-0180 |
| Manufacturer | Veichi |
| Weight | 1.400 kg |
| Voltage | 48Vdc |
| Application | Low voltage, price optimised (V7E) |
| Velocity | 3000rpm |
| Feedback | Tamagawa |
| Holding brake | With brake |
| Temperature sensor | KTY |
| Protection class | IP67 |
| Motor flange | 60x60mm |
